Electrical Spec.

Options

Rating voltage

380VAC

Flange for set up

Rating current

150A /Ring，500A /Ring，1000A /Ring

The wire exit direction,length is optional

Insulation resistance

1000MΩ@500VDC

Can combine more circuits:1-126Ring

Dielectric strength

600VDC@50Hz

Higher voltage and current capacity

Electrical noise

10mΩ@6VDC,50mA, 5Rpm

Higher rotational seed:800Rpm

Mechanical Spec

Environment

Speed

300Rpm

Working temperature

-40℃~+80℃

Torque

60N.cm

Mechanical vibration

MIL-SID-810E

Seal class

IP54 (IP68Options)

Humidity

10% to 90% RH non-condensing

Contact material

Precious Metal

Materials

Lead Free,RoHS compliant

Lead Wire

Teflon wire

CE Certified

YES

Life

500million revolutions
