Electrical Spec

Channe 1

Channe 2

Peak Power(KW)

3.0KW

3.0KW

3.0KW

3.0KW

3.0KW

3.0KW

Average Power（W)

 200

200

200

200

200

200

VSWR bei/at 40GHz

VSWR≤1.2

VSWR≤1.8

VSWR≤1.2

VSWR≤1.4

VSWR≤1.8

VSWR≤2.5

VSWR-WOW

≤0.05

≤0.05

≤0.1

≤0.1

≤0. 1

≤0.4

insertion loss

≤0.1dB

≤0.7dB

≤0.5dB

≤0.5dB

≤1.5dB

≤1.5dB

insertion loss-WOW(db)

≤0.05dB

≤0.05dB

≤0.1dB

≤0.1dB

≤0.3dB

≤0.3dB

insertion loss-WOW（db)

≥50dB

≥50dB

≥50dB

≥50dB

≥50dB

≥50dB

phase-WOW

≤1

≤1

≤2

≤2

≤2

≤2

Connection

SMA socket

SMA socket

SMA socket

SMA socket

SMA socket

SMA socket
